Sanyo PLC-XU105 High Brightness Digital LCD Projector


DISCONTINUED
FOR CURRENT SANYO PROJECTORS CLICK HERE
Sanyo PLC-XU105 Reviews:


/5

The PLC-XU105 from Sanyo is a good multimedia projector that can handle being set up in difficult conditions thanks to an extremely high brightness level.

Another great feature offered is instant shut-down. Once you've finished with your presentation you can switch off the projector immediately, without waiting for any additional cooling by the fan. This is a definite bonus if you're on the move, and it is especially surprising considering its high brightness levels.


AMAZING BRIGHTNESS LEVEL FOR AN ULTRAPORTABLE
The PLC-XU105 projects an outstanding brightness level of 4500 ANSI Lumens, illuminating effectively in well lit conference rooms.

POWER-OFF AND GO AND DARK-SURFACE PROJECTION CAPABILITY
No need to wait for the projector to cool down. You can disconnect the power cord right after your presentation without worrying about overheating. And speaking of presentations, for more effective presentations in rooms with dark-surfaced walls, the PLC-XU105 projector features the blackboard (green) mode, which automatically adjusts the white balance and gamma correction to project a detailed image without a screen.

SMART AUTO INPUT SEARCH AND AUTO VERTICAL KEYSTONE CORRECTION
Aimed to reduce setup time, the Auto Input Search function detects various input signals and automatically selects the correct mode to project images from their original sources. Another time-saving function called the Auto Vertical Keystone Correction automatically compensates for keystone picture distortions during setup.

USER-SPECIFIED START-UP SCREEN
To create a more professional presentation, logo and image files may be captured for display during the projector’s countdown start-up sequence.

SECURITY FEATURES
A PIN code lock provides a setting for security. The PLC-XU105 projector cannot be operated without a four-digit number.

VARIABLE AUDIO OUT
This convenient feature allows the user to control the audio level right from the projector. The centralization of video and audio controls from the projector helps in educational applications by ensuring the technical quality of the presentation and eliminating the fuss of separate outside audio controls.

360° Degree Tilt Angle
The PLC-XU115/ XU105 can project images while they are tilted 360 degrees around their horizontal axis in either direction - for more flexible setup.

NOTE: Be sure to set the lamp control to High and the fan control to MAX in the setting menu when the projector is inclined between +40 degrees and +140 degrees to the horizontal plane.
Wide 1.6x Zoom Lens
The wide-range 1.6x zoom lens lets you project a 100" image from as close as 2.4 meters from the screen, to as far away as 3.8 meters. That makes it a lot easier to find suitable places to set the projector up.



Specifications

Resolution XGA (1024 x 768)
Brightness (typical) 4500 ANSI Lumens
Uniformity 85 % (corner to center)
LCD Panel System 0.8” TFT p-Si x 3 w/Micro Lens
Number of Pixels 2,359,296 (786,432 x 3)
Contrast Ratio 500:1 (lamp mode ”Auto”, image mode ”Dynamic”)
Projection Image (diagonal) ”-300” 40
Aspect Ratio 4:3
Throw Distance 3.1’-37.6’
Zoom/Focus Manual (1:1.6 zoom)
Up/Down Ratio 9:1
Digital Keystone Correction Vert. +/- 40°
Projection System Dichroic mirror & X prism system w/ PBS
Projection Lens F1.7-2.5 / f0.76”-1.19”
Lens Throw Ratio 1.15 – 1.85 :1
Projection Lamp 275W NSHA
Scanning Frequency H 15-100kHz; V 50-100Hz
Dot Clock 140 MHz
Color System NTSC/PAL/SECAM/NTSC4.43/PAL-M&N
Computer Compatibility UXGA, WXGA, SXGA, XGA, SVGA, VGA,
MAC analog
Sound Output One-piece, 1-watt Mono
Voltage 100-240V AC; 50/60/Hz
BTU Rating 1082
dB Rating 35dBA / 31dBA (normal/eco)
Power Consumption 317W
Dimensions (WxHxD) 13.2” x 3.1” x 10.1” (not including protrusion)
Net Weight 7.7lbs.
User Maintenance Clean air filters, replace lamp assembly
PC Input Terminals D-Sub15 x 1
�� D-Sub15 x 1 (RGB, component, scart RGB)
�� Audio x 1 (stereo mini-jack)
Video Input Terminals Composite video (RCA x 1) �� S-Video
(mini-Din 4-pin) �� R & L/mono audio (RCA x 2)
Output Terminals D-Sub15 x 1 (monitor out)
��Variable audio (stereo mini-jack)
Service Port Terminal Mini DIN 8-pin
Included Accessories I/R Remote control �� 2 AA batteries
�� Owner’s manual (quick manual & CD-ROM)
�� VGA cable �� PIN code label �� Soft carry bag
�� AC power supply cord �� Strap for lens cap
�� Serial control cable (POA-MCSRL)
Optional Accessories �� POA-CACOMPVGA – Component video cable
�� 610 333 9740 – Replacement lamp
�� 945 086 4965 – Replacement remote

Supplied Accessories
Remote
Case
Rear Panel
