Epson EB-L1070UNL LCD High Brightness Full HD Laser Projector




Your Price: $11499

Flat Rate Freight!
$22 Insured Australia Wide.
Pick up Available

Quick Facts:
Native Resolution: WUXGA 1920 x 1200 16:10
Brightness: 7000 ANSI Lumens
Maximum Contrast: 2,500,000:1
Weight: 16.9kg
Fan Noise: 36 / 30db (eco)
Warranty: 3 Years / 20,000 hours
Laser Warranty: 3 Years / 20,000 hours
Laser Life Up To: 20
- Lens Options
- 4K Enhancement

- Vertical Lens Shift (+/- 67%)
- Horizontal Lens Shift (+/- 30%)
- Powered Lens Shift
- Powered Zoom & Focus

- 360° Installation (v&h axis)
- Portrait Projection
- Geometric Correction

- HDBaseT Compatible

Epson EB-L1070UNL Large Venue Laser Projector

The Epson EB-L1070UNL is designed for demanding installations where the solid state laser light source can be run heavily in a lit environment and will produce a stunning strong image. Without the cost of lamps, downtime, and technicians you would expect with a lamp based projector. Epson back it for 3 years or 20,000 hours and have a selection of ten different lenses to customize the installation point. With both lens shift and keystone correction the EB-L1070UNL is also perfect for tricky off centre setup.

Lens type Short Throw Lens 1 Short Throw Lens 2 Wide Throw Lens 1 Wide Throw Lens 2 Middle Throw Lens 1 Middle Throw
Lens 2
Middle Throw
Lens 3
Middle Throw
Lens 4
Zoom Lens
Reference ELPLU03S
Screen size range 80-300 inch 50-300 inch 50-300 inch 50-300 inch 50-300 inch 50-300 inch 50-300 inch 50-300 inch 50-300 inch
Epson EB-L1070UNL Distance Chart (Examples for common Sizes)
Throw Ratio 0.65-0.78:1 0.87-1.05:1 1.04-1.46:1 1.62-2.22:1 1.42-2.28:1 2.16-3.48:1 3.32-5.06:1 4.85-7.38:1 7.21-10.11:1
110" (16:10)
1.54m to 1.86m 2.08m to 2.51m 2.48m to 3.47m 3.86m to 5.27m 3.43m to 5.51m 5.12m to 8.27m 7.9m to 12.00m 11.53m to 17.52m 17.13m to 24.01m
130" (16:10)
1.83m to 2.20m 2.46m to 2.97m 2.95m to 4.11m 4.58m to 6.24m 4.06m to 6.52m 6.07m to 9.79m 9.36m to 14.21m 13.67m to 20.75m 20.31m to 28.43m
180" (16:10)
2.55m to 3.06m 3.43m to 4.14m 4.11m to 5.71m 6.36m to 8.68m 5.64m to 9.04m 8.43m to 13.58m 13.01m to 19.72m 19.02m to 28.82m 28.24m to 39.49m
Ultra Short throw Lens
(No Lens Shift or Zoom)
ELPLX01 Screen size range
Epson EB-G7905UNL Distance Chart (Examples for common Sizes)
Throw Ratio 0.35:1
110" (16:10)
130" (16:10)
180" (16:10)
ELPLX01 $9099
101-400 inch


  • Laser Light Source – Experience astonishing quality and reliability
  • Up to 3x Brighter Colours, and reliable performance1 – 3LCD, 3-chip technology
  • 4K Enhancement – Go beyond High Definition with 4K enhancement and native WUXGA (1920 x 1200) resolution for presentations, videos, digital signage and more
  • Up to 7,000 Lumens – Deliver captivating images in virtually any venue
  • Colour Uniformity – Keep images consistent and maintenance to a minimum with manual colour correction
  • Edge Blending – Combine multiple individual images to create one seamless giant image
  • Professional Tool – Efficiently setup multiple projectors straight out of the box with new large venue application software
  • Wireless LAN Enterprise Security – Connect projectors in a secure wireless network environment
  • 3x Digital connections – Digital quality and distance flexibility
  • HDBaseT – Transmit Full HD video and audio, Ethernet and Serial communication through a single CAT 5/6 cable that can be extended up to 100m
  • 360° Installation – Install on any plane, from horizontal to vertical and everything in-between
  • Powered Lens Shift, Zoom and Focus – Project perfectly uniform images with a new stepping motor and store up to 10 lens settings
  • Eleven Optional Lenses2 – Choose the ideal powered lens for your venue from a wide range including ultra-short throw and long throw
  • Content Playback – Save videos and photos to USB flash memory and project them instantly without the need of a PC

1 Colour brightness(colour light output) in brightest mode, measured by a third-party lab in accordance with IDMS 15.4. Colour brightness will vary depending on usage conditions. Top-selling Epson 3LCD projectors versus top-selling 1-chip DLP projectors based on NPD sales data for May 2017 – April 2018.

2Please refer to lens compatibility chart

3LCD Technology
All Epson projectors are based on 3-chip LCD technology for amazing colour, incredible detail and solid reliability. 3LCD’s 3-chip architecture dedicates an entire chip to process each primary colour – red, green and blue, continuously. Unlike single-chip technology that delivers colour sequentially, you get full-time colour. The result is vibrant, realistic images and video all delivered with 3LCD’s true-to-life colour.

Up to 3x Brighter Colours with Epson Projectors*
Epson projectors use 3LCD Engines that have no colour wheel with a white segment and therefore don't force a tradeoff between white and colour brightness.

In fact, Epson projectors have up to 3x Brighter Colours than their leading competitive 1-chip DLP projectors*. All Epson projectors list both White Brightness and Colour Brightness specifications, and all have high Colour Brightness.

*Colour brightness(colour light output) in brightest mode, measured by a third-party lab in accordance with IDMS 15.4. Colour brightness will vary depending on usage conditions. Top-selling Epson 3LCD projectors versus top-selling 1-chip DLP projectors based on NPD sales data for May 2017 – April 2018.

Laser Light Source
Experience astonishing quality and reliability with Epson’s new laser light source. The newly designed laser light source and advanced electrostatic filter deliver 20,000 hours of maintenance-free use and consistent performance for total peace of mind during important presentations.
Laser Light Source
4K Enhancement

4K Enhancement

Take presenting into the future with support for 4K and the ability to upscale Full HD (1080p and WUXGA) content with Epson’s 4K Enhancement Technology – which shifts pixels diagonally – delivering crisp images beyond high definition.

Up to 6,000 lumens
Powered by 3LCD technology and Epson’s laser optical engine, the EB-L1070UNL is capable of producing White Light and Colour Light Output of up to 7,000 lumens in WUXGA resolution, delivering captivating images in virtually any venue. The laser light source also lets you take control of brightness with precise adjustment in increments of 1% and a constant brightness mode that maintains brightness at a specified level.


EB-L1070UNL resolution

High Resolution
Epson EB-L1070UNL features native resolution up to WUXGA (1920 x 1200), delivering high quality images and crisp, sharp text without any distortion.

WUXGA resolution is ideal for any application requiring Full HD, including BluRay content, graphic intensive programs, film slides, and any application requiring exceptional detail.

Powered Lens Shift, Zoom and Focus
The motorised lens shift covers a wide range, giving you a great deal of flexibility when installing the projector. A newly adopted stepping motor lets you make highly precise adjustments when employing edge blending, stacking and other techniques. Adjustments can be made via remote control or over a network, enhancing usability even for ceiling-mounted projectors.
EB-L1070UNL lens shift

Colour Uniformity
Keep images consistent and maintain images that have become uneven over time between multiple projectors with manual colour correction.

Lens Position Memory
Up to 10 settings can be stored in the projector memory, including shift positions, focus and projection sizes.

EB-L1070UNL HDBaseT Incredible HDBaseT and diverse connectivity
Connect with virtually any system including HDBaseT, DVI-D, HDMI, VGA, BNC and LAN connectivity. Cutting-edge HDBaseT technology means just one single CAT-5/6 cable carries Full HD video, audio, network and control commands up to 100 metres to accommodate large venues. No need for additional cables, signal repeaters or added labour.
360 Degree Projection
The Epson EB-L1070UNL can be rotated 360° in any direction for off-axis positioning flexibility. As a result, they can be used for a wide range of applications, such as projecting on the ceiling or floor, or as part of a rear-projection system. Epson technology keeps the projector running without compromising performance or causing overheating.
EB-L1070UNL 360 installation

Edge Blending
Enhance the experience with seamless panoramic, multi-screen images that blend edges by matching colour and brightness perfectly, even in areas that overlap.

EB-L1070UNL Edge Blending

Point Correction
Make smooth adjustments of distorted projection image by shifting each of the points laid out on the grid pattern.

EB-L1070UNL point correction

Arc Correction
Using arc correction, you can adjust each side of a projected image in an arch or barrel-shaped way, making it easier than ever to get a perfectly rectangular image.

EB-L1070UNL arc correction

Corner Wall and Curved Surface Projection
Quickly and precisely correct any vertical or horizontal distortion of an image with Epson’s curved surface and corner wall projection. These features allow for greater flexibility when choosing a projection surface. Enhance your viewers experience by projecting your content in a unique environment with ease.

Professional Tool
Setup multiple projectors straight out of the box with new large venue application software. Epson Professional tool allows you to adjust and control images projected on a network with high-end projector setup features such as geometry correction, image layout adjustment, lens control and edge blending. Exclusively bundled to Epson L-Series projectors, large scale presenting has become much easier and flexible.

EB-L1070UNL professional tool

Content Playback
Save videos and photos to USB flash memory with our dedicated application, and project them instantly without the need for a PC.

Content Management
Epson Projector Content Manager Software enables users to quickly and easily sort and distribute content without any additional costs. Key features of the software include:

  • Creating playlists
  • Adding visual effects
  • Setting up remote shortcuts
  • Applying custom filters
  • Scheduling playlsits

DICOM Simulation Mode
DICOM (Digital Imaging and Communication in Medicine) is a standard for handling, storing, printing and transmitting medical imaging information. The projector’s DICOM Simulation Mode enables users to reproduce images with an advanced grayscale level that simulates DICOM Part 14. This mode is ideal for viewing grayscale medical images, such as X-rays, for training and educational purposes.

Collaborative presenting
Multiple users can connect simultaneously to one projector using Epson iProjection software which allows you to display four individual PC screens simultaneously over the network (wired or wireless), with up to 50 users connected to the same projector. This feature is a great tool for meetings or classroom projects where multiple users want to present and compare their screens.
EB-L1070UNL Collaborative presenting

Simple control
Use features such as Epson Projector Management software to monitor and control projectors, with fleet control across a network or on a web browser to keep track of up to 2,000 projectors. The latest models feature a newly designed OSD Control Pad function that shows a representation of lens conditions on a smart device.

Ultra Short Throw Lens
The ELPLX01 is a UST lens to accommodate high brightness EPSON laser projector models ranging from 5klm to 8klm. This produces images from 100 inches to a massive 400 inches at a throw distance of 0.74m – 3.1m respectively and has lens shift of +17 vertical and +/- 10% horizontally for added flexibility. The UST lens is also available in white (ELPLX01W).

EB-L1070UNL ultra short throw

Eleven optional lenses
For added flexibility, the EB-L1070UNL offers a total of eleven lenses, including middle, wide, long, short and ultra-short throw that allow users to choose the lens most suited for their environment. A quick-release lever allows for a fast, easy lens exchange.
Ceiling Mounts
Both standard and low profile ceiling mounts are available to give you even more installation flexibility across the L Series. Both mounts are now grey in colour to easily integrate into any colour scheme.
EB-L1070UNL mount

  EB-L1070UNL Projector, 3m 10A Power Cable, Quick Start Guide, Remote Control, 2 x AA Batteries, Cable Cover, Lens connector cap, Registration Card
Projection System RGB liquid crystal shutter projection system
LCD Panel 0.76-inch (D10)
Zoom 1 - 1.61 (Optical)
Screen Size (Standard Lens) 50" to 1000" [1.53m to 31.57m] (Zoom: Wide)
50" to 1000" [2.48m to 50.44m] (Zoom: Tele)
Projection Distance (Standard Lens) 100" screen 3.11m - 5m
Throw Ratio 1.44 (Zoom:Wide), 2.33 (Zoom:Tele)
Projection Lens F Number 1.7-2.3
Projection Lens Focal Length 24.0mm - 38.2mm
Focus Method Powered
Colour Light Output 7,000 Lumens
White Light Output 7,000 Lumens
Resolution WUXGA
Native Aspect Ratio 16:10
Contrast Ratio 2,500,000:1
Light Source Laser Diode
LD Input Power 115 W
Keystone Correction (Standard Lens) Vertical: -45 to +45 degrees
Horizontal: -30 to +30 degrees
Lens Shift (Standard Lens) Vertical: -67% to +67% (Powered)
Horizontal: -30% to +30% (Powered)
Input: Video 1 x 5BNC
Input: Computer 1 x D-sub 15-Pin (RGB)
Input: Digital 1 x HDMI, 1 x DVI-D, HDBaseT
Input: Audio 3 x Stereo mini
Input: Control 1 x RS232c, 1 x Stereo mini (Remote)
Input: Network I/O 1 x RJ45, 1 x USB Type A (for optional Wireless LAN unit, Content Playback)
Input: HDBaseT 1 x RJ45
Wireless Connectivity Optional
Output: Video 1 x Monitor Out (via D-sub 15-pin)
Output: Audio 1 x Stereo mini
Epson Projector Management (Network & Control) Yes
Epson iProjection (Multi-PC Projection) Yes
Epson Professional Tool Yes
Wireless LAN Optional
4K Enhancement Yes
Lens Position Memory Yes (10 positions)
Split Screen Yes
Edge Blending Yes
Curved Screen Projection Yes
Corner Wall Projection Yes
Frame Interpolation Yes
360 Degrees Projection Yes
Direct Power On/Off Yes
Security Kensington® – style lock provision
Wireless LAN Unit Lock
Security cable hole
Colour Modes Dynamic, Presentation, Cinema, BT.709, Natural, DICOM SIM, Multi-Projection
Dimensions D x W x H (Including Feet) 484 x 545 x 189 mm
Weight 16.9
Projector Warranty 3 Years*
Power Consumption: LD On 299W
Power Consumption: Standby 2W
Noise Level Normal/Quiet: 36/30 dB


Rear Panel

EB-L1070UNL Rear
