Epson EB-X51 LCD High Brightness Data Projector

Epson EB-X51
Delivery

DISCONTINUED

For current models Click Here:
Epson

2 year warranty
australian stock
insured delivery
XGA Resolution

Specifications

  • XGA 1024x768 4:3
  • 3800 ANSI Lumens
  • 16,000:1 Contrast
  • 2.5kg Weight
  • 37/28db(eco) Fan Noise
  • 2 Year Warranty
  • 1 Year/750Hr lamp Warranty
  • Est. Lamp Life up to 12,000hrs

Key Features

  • Horizontal &Vertical Keystone
  • USB to laptop Connection
  • HDMI Connection
  • USB reader (JPEG, GIF, BMP, AVI)
  • Instant Off
  • Presentation Wireless - Optional

Epson EB-X51 Throw Distance Chart

Throw Ratio: 1.48-1.77:1
Examples of installation distance for some popular screen sizes.
Image Size Installation Distance
84" (4:3) 1650x1237mm From 2.5m to 3.0m
100" (4:3) 2030x1523mm From 3.0m to 4.3m
120" (4:3) 2360x1770mm From 3.6m to 4.3m
150" (4:3) 3050x2285mm From 4.6m to 5.3m

Epson EB-X51 Data Projector

The EB-X51 features the traditional 4:3 aspect ratio perfect for replacing an older projector and keeping the squarer screen without the additional outlay of upgrading the whole setup to HD widescreen. The EB-X51 is quite powerful at 3800 lumens making it perfect for lights on presentations and with a long lamp life of up to 12,000 hours can be run heavily without the need worry about replacement lamps. Weighing a mere 2.5kg the EB-X51 is also easy to transport.

KEY FEATURES:
  • Up to 3x brighter colours and reliable performance* – 3LCD, 3-chip technology
  • XGA Resolution – featuring 4:3 aspect ratio (1024x768)
  • Amazing Colour Brightness – up to 3,800 Lumens colour brightness and 3,800 Lumens white brightness
  • Split Screen – project from two different image sources for flexible options in the workplace
  • Ultra-Portable – weighing in at only 2.5kg for easy travel between home and the office
  • Captivating Sound – enjoy a built-in stereo speaker for life-like sound
  • Simple Set-Up – Auto Vertical correction and Easy-Slide Horizontal image correction to help get up and running in no time
  • Low Cost of Ownership – long-life, cost efficient lamps and a High Efficiency Filter extends the life of your projector and allows for hassle free maintenance
  • Easy to Use – a new simple welcome guide and easy-to-use remote puts all the most commonly used functions right at your fingertips
  • Auto Power On – Simply plug-in a HDMI, USB or VGA cable to turn the projector on
  • Up to 2 Year Projector warranty – enjoy peace of mind
EB-X51 True Colour

Brighter, vivid projection

White brightness alone cannot bring the True Colours you see every day. While other manufacturers of 1-chip DLP technology believe they can improve image quality by just increasing the brightness of their projectors’ white light output, Epson ensures that its projectors combine brightness and True Colours to create vibrant and realistic images with 3LCD technology across every projector model.

Up to 3x Brighter Colours with Epson Projectors*

Epson projectors use 3LCD Engines that have no colour wheel with a white segment and therefore don't force a trade-off between white and colour brightness. In fact, Epson projectors have up to 3x Brighter Colours than their leading competitive 1-chip DLP projectors*. If you are looking for business and education projectors or 720p home entertainment projectors, know that choosing Epson projectors means up to 3x brighter colours. If you are looking for 1080p home entertainment projectors, you consistently get 2x and up to 3x Brighter Colours than competitor 1-chip DLP projectors*. All Epson projectors list both White Brightness and Colour Brightness specifications, and all have high Colour Brightness.

*Colour brightness(colour light output)_in brightest mode, measured by a third-party lab in accordance with IDMS 15.4. Colour brightness will vary depending on usage conditions. Top-selling Epson 3LCD projectors versus top-selling 1-chip DLP projectors_based on NPD sales_data for May 2017- April 2018.

Brilliant Images in any setting

With both colour and white brightness up to 3,800 lumens, EB-X51 makes it easy to enjoy brilliant content in any setting, even well-lit rooms. While the light weight and compact size of these projectors enable them to be carried from room to room, they are also capable of highly visible images thanks to high brightness and a superior 16,000:1 contrast ratio.

EB-X51 Brightness

Large Image Size

While conventional panels are limited to a pre-determined height and width, projectors have no such constraints. With the image size expanding up to 300”, your audience can easily read and understand the information you’re sharing.

EB-X51 Large Image Size

Travel Light

Weighing in at only 2.5kg, these projectors are perfect for being carried from room-to-room around the office. The switch between home and work has never been more convenient.

Flexible Positioning

Position your projector almost anywhere in the room and still get a correctly proportioned image with auto vertical correction and Easy-Slide horizontal image correction. Additionally, optical zoom up to 1 - 1.2x enables you to adjust the image easily and quickly, even in a limited space.

EB-X51 Keystone

Split Screen

Split Screen allows inputs from two separate sources to be displayed side by side on the same screen. With different layout options you can display video and presentation materials, and run video on both screens. This function allows the projector to perform a dual role, eliminating the need for a second screen, perfect for meeting rooms with limited spaces. Additionally, classroom lessons can be made more engaging by connecting a projector with a document camera and a PC or tablet.

EB-X51 Split Screen

EB-X51 Iprojection Wireless

Epson iProjection (Optional)

Wirelessly display content from your iOS or Android mobile devices as well as PCs, including Chromebook with the Epson iProjection App. Easily share information on the big image from up to 4 connected devices simultaneously. Just turn on the projector, use the Epson iProjection app to scan the on-screen QR code, and share content on the big screen. This application allows you to travel light and present from your mobile device.

Quick, Convenient Control

Enjoy fast set-up with the Auto Power On function, as the projector startup is activated via USB, HDMI, or VGA cable insertion. Slide the lens shutter closed at any time and the projector will go into A/V mute (sleep mode) so you can stop and start your presentations when needed. Then, with Instant Off, simply remove the power cord of the projector, pack up and go.

EB-X51 AV Mute

EB-X51 Projector Lamp

Low Cost of Ownership

Save on costs with a longer lamp life and a high efficiency filter, allowing for hassle free maintenance. The EB-X51 series lamps last up to 12,000 hours in ECO mode, the equivalent of 10 years’ worth of use. (Using 6 hours for 200 days)

Connectivity Options

These projectors support a range of connectivity options, including HDMI, VGA and USB, allowing you to connect to the latest digital devices without the need for adaptors.

EB-X51 Connectivity

EB-X51 PC Free USB

PC Free Presentations With USB Meadia Reader

Easily present basic files from a memory stick without the need for a media player or computer. Image files and even video can be presented directly from a memory stick for extra versatility and portabilty. For best results format the stick file format to Fat16/32. File format and size limits apply see manual for more details.

EB-X51 Home Screen

Simple Set-up

An easy-to-use home screen offers quick access to a variety of useful functions. Also, all source information, no matter what the source input is, can be seen at a glance. Wireless connections can be made effortlessly because all the information you need is right there on the screen.


Specifications
PRODUCT NAME EB-X51
PRODUCT CODE V11H976053
TECHNOLOGY
Projection System 3LCD
LCD Panel 0.59-inch
Light Source Lamp
Resolution XGA
Colour Light Output 3,800 Lumens
White Light Output 3,800 Lumens
Native Aspect Ratio 4:3
Contrast Ratio 16,000:1
Lamp Type 210 W UHE
Keystone Correction (Standard Lens) Vertical: -30 to +30 degrees
Horizontal: -30 to +30 degrees
OPTICAL
Zoom 1 - 1.2 (Optical Zoom)
Screen Size (Standard Lens) 30" to 300"
Projection Distance (Standard Lens) 60" screen 1.8 - 2.17 m
Throw Ratio 1.48 (Zoom: Wide)
1.77 (Zoom: Tele)
Projection Lens F Number 1.49 - 1.72
Projection Lens Focal Length 16.9 mm - 20.28 mm
Focus Method Manual
Offset 8:1
CONNECTIVITY
Input: Video 1 x RCA (Yellow)
Input: Computer 1 x D-sub 15-Pin (RGB)
1 x USB 2.0 type B
Input: Digital 1 x HDMI
Input: Audio 2 x RCA (Red / White)
Control: I/O
Network: I/O 1 x USB 2.0 type A
Wireless Connectivity Optional (ELPAP11)
Output: Video
Output: Audio
ADVANCED FEATURES
Built-in Speaker 2 W
Epson Projector Management (Network & Control) Yes
Epson iProjection (Multi-PC Projection) Yes
Wireless LAN Enterprise Security
Miracast
Split Screen Yes
Auto Keystone Correction Vertical: -30 to +30 degrees
Horizontal Slide Keystone Correction Yes
Instant Off Yes
Direct Power On Yes
Security Kensington - style lock provision
Colour Modes Dynamic, Presentation, Cinema, sRGB, Blackboard
GENERAL
Dimensions D x W x H (Including Feet) 237 x 302 x 82 mm
Weight 2.5 kg
Projector Warranty 2 Years
Lamp Life (Normal/Eco) 6,000 h / 12,000 h
Power Consumption: Lamp On 327 W
Power Consumption: Standby 2.0 W
Noise Level (Normal/Eco) 37 / 28 dB

What's in the Box
EB-X51 remote control
Remote Control
power cord
Power Cord

Rear Panel

EB-X51 rear panel
