Hitachi LPTW3001 LCD HD Ultra Short Throw Projector - Optional Wall Mount



LPTW3001





laser

Australian 5 Year Warranty


Hitachi Logo


Your Price: $2949

Flat Rate Freight!
$22 Insured Australia Wide.
Pick up Available

Wall Mount $199

Quick Facts:
Hitachi LPTW3001 Throw Distance Chart (Examples for common Sizes) T/R: 0.3:1
Image Size Installation Distance
(Approx. To Lens)
83" (16:10) 1790x1120mm From 0.54m to 0.54m
98" (16:10) 2110x1320mm From 0.63m to 0.63m
SPECIFICATIONS
Native Resolution: WXGA 1280 x 800 16:10
Brightness: 3300 ANSI Lumens
Maximum Contrast: 500,000:1
Weight: 7.4kg
Fan Noise: 34 / 28db (eco)
Warranty: 5 Years / 20,000hrs
Laser Warranty: 5 Years / 20,000hrs
Laser Life Up To: 20,000hrs
FEATURES
- Vertical Keystone Correction
- Horizontal Keystone Correction

- 2x HDMI Connection
- Powerful 16W Speaker
- USB stick reader (Jpeg / Video)

- Pen Interactive
- Optional Finger Interactive Module
- Optional Wireless
- Optional Wall Mount

Hitachi LPTW3001 LCD Laser HD Ultra Short Throw Projector

Hitachi have a real winner with the LPTW3001 which produces a clear HD image but does away with replacement lamps instead the LPTW3001 is powered by a long life laser which gives you a massive 20,000 hours of operation. This does away with all the maintenance, down time and replacement lamp cost associated with the old fashioned projectors and also comes with a 5 year 20,000 hour warranty on the laser.
The LPTW3001 is ultra short throw so perfect to have right at the front of the room, no shadows or blinding light for the presenter. With an optional wall munt you can install it so it is out of the way and it is capable of image sizes up to 130”.

These ultra short throw LCD laser projectors from Hitachi are specifically designed to enhance the visual experience – beit audience or presenter. Vivid colours, bold graphics and crisp text. Our projectors do it all, no matter what the environment. With up to 4,200 ANSI lumens of brightness and WXGA 1280 x 800 resolution, our ultra short throw projectors provide the perfect compatible solution. They also feature a high contrast ratio, cloning function enabling you to copy settings data from one projector to others of the same model, and are wireless presentation ready. Plus, embedded networking gives you the ability to manage and control multiple projectors over your LAN (scheduling of events, centralised reporting, image transfer, and email alerts). Most importantly, the high performance of our projectors is exceptionally reliable and offers a very low cost of ownership.

Features

  • WXGA Resolution, 3,300 Lumens
  • 500,000:1 Contrast Ratio
  • Laser Phosphor Light Source
  • 20,000 hours expected light source
  • Interactive Pens / Multi-pen capability
  • Optional finger touch module
  • New & improved wall mount (HASWM06) supports up to 110”
  • Wireless Network Option
  • 3LCD
  • Auto & Manual calibration
  • 16 Watt Internal Speakers
  • HDMI x 2 (HDCP compliant, HDMI 1 shared with MHL)
  • 5 Years or 20,000 Hours (whichever comes first) On Site Warranty
  • StarBoard Software supplied – Hitachi’s very own interactive software suite, for when you’re ready to move beyond just annotation.

Interactive Features

  • Interactive Software: This product includes a drawing application that offers more sophisticated drawing functions.
  • Neatly Convert Letters or Figures: You can automatically convert freehand shapes into geometric objects and handwriting into text on projected images. These operations are easily accomplished with the interactive pens.
  • Select a Variety of Useful Tools: The interactive pen lets you operate a compass, ruler, protractor, stopwatch and other useful tools on the projected image, making lessons even easier to understand.
  • Advanced Writing/Drawing Capabilities: This projector comes with a built-in function allowing you to directly draw and write on the projected screen without a PC.
  • Directly Draw on the Projected Screen: You can write and draw on images projected from connected devices such as a document camera.
  • Save and Open Drawn Screens: You can save the image drawn on the projector screen. This enables you to easily manage what you’ve taught in the past.
  • Finger Touch Option: This projector incorporates the optional finger touch unit that enables the projector to detect finger touch activity on the screen area. It allows users to annotate and interact with the material presented. Instead of simply showing static images, students and teachers can interact with on screen material for hands-on interactivity that brings learning to life. When using the finger touch unit in a bright environment, auto-calibration may not be used. Must be used on a flat screen. The finger touch unit may not be used in locations where there is sunlight or light from an incandescent light source.
  • Convenient Painter Tool Equipped with the Pen, Eraser, Undo, Redo, functions: You can also change the pen colour and thickness. With the easy-to-use Painter tool bar, you can teach classes smoothly.
  • Variety Rich Templates: You can conveniently use the interactive function with over 100 pre-installed templates including graphs, graphic organizers, plain colour and many more.
  • Multiple Interactive Pens: With up to 6 interactive pens, pupils can do more than just watch–they can interact with the onscreen content. Let them enjoy providing answers, showing their understanding and becoming involved in lessons like never before.
  • Windows® Multi Touch: Windows® 8.1/10 multi touch allows users with touch enabled Windows® 8.1/10 systems to operate the PC directly from the interactive screen with up to 6 pens or touches including Windows® 8.1/10 gesture.
  • Smart Device Control: Plugging the optional USB wireless adapter into the projector and using the dedicated free online application developed by Hitachi, projectors can be controlled from a tablet or smartphone.
  • Starboard Interactive Presentation Software: Hitachi’s world-class interactive StarBoard Software (SBS) is the next standard in collaboration, information sharing and dynamic presentation software. With a customizable interface and toolbar, Starboard streamlines your workflow and improves production. While you would expect to pay hundreds of dollars extra for similar interactive software from the competition, Hitachi bundles it as a standard feature with each interactive projector.
Accentualizer
Hitachi original technology makes pictures look more real by enhancing sharpness, gloss and shade to make pictures as clear as pictures on a flat-panel device. You can also adjust the effects by three levels according to your surroundings so that the colors of projected images are the actual colors of the objects they represent.
LPTW3001 Accentualizer

Aspect Zoom
Aspect Zoom makes the maximum image size on the screen while keeping the aspect of the imag
e.
LPTW3001 Aspect zoom

HDCR2 (High Dynamic Contrast Range)
When average projectors are used in bright rooms, the darker colors of an image deteriorate and images become unclear. Using this function, blurred images caused by room lighting or outside light sources are corrected, and an effect similar to increasing contrast occurs. The recent enhancement to HDCR2 achieves not only auto tone enhancement but also auto color enhancement. This results in clear and vivid images even in bright rooms.
LPTW3001 HDCR2
CPAW3001 Cloning function Cloning Function
Copy setting data from one projector to others of the same model via USB memory. Cloning not only saves almost all PJ settings such as gamma and keystone via USB memory, it saves countless hours in setup and installation

CPAW3001 MHL MHL™
MHL (Mobile High-Definition) allows users to mirror their phone/ tablet screen with the projector display. It is compatible with any and all apps.

CPAW3001 Perfect Fit 2 Perfect Fit 2
Enables the user to adjust individual corners and sides independent of one another. Perfect Fit 2 provides vertical and horizontal digital correction of either barrel or pin cushion distortions. This feature helps correct geometric and complicated distortions. Perfect Fit 2 allows the projected image to fit correctly to the screen quickly and easily.

CPAW3001 Cloning function Projector Quick Connection App For Mobile Devices
Our iOS and Android applications offers projector control and also provides the capability to display photos, document files and web site contents. Available for iPad®, iPhone® and Android devices. Works over your LAN via your RJ-45 port or via an optional USBWL5G wireless adapter.

CPAW3001 Cloning function Input Source Naming
Users can name input sources in simple language instead of factory default names.

CPAW3001 Cloning function Microphone Input
A microphone can be used via the jack located on the input panel. Allows for more dynamic presentations even in standby mode.

CPAW3001 Cloning function Network Control, Maintenance and Security
Embedded networking gives you the ability to manage and control multiple projectors over your LAN. Features include scheduling of events, centralized reporting, image transfer and e-mail alerts for reactive and routine maintenance.

CPAW3001 Cloning function PC-Less Presentation
By using a USB memory stick or other storage device, you can use the projector without a computer for Jpeg or video presentations. Menus are easy to see with a thumbnail display. Additionally there is also a slideshow and video function.

CPAW3001 Cloning function PIN Lock / MyScreen / MyText
PIN lock protection can limit projector users. MyScreen PIN lock keeps captured images on the startup screen. Users can set any name logo to MyScreen, clearly identifying ownership. MyText provides the ability to write text on the startup screen such as model. name, serial number or location.

CPAW3001 Cloning function PJMessenger
PJMessenger function allows you to send and display text messages and audio alerts on your networked projectors. It is an easy and efficient way to send announcements out to multiple units.

CPAW3001 Cloning function Present Content via LAN
Hitachi’s suite of networking software allows you to easily send content directly from your PC to the projector via your LAN connection.

CPAW3001 Cloning function Template Function
Line templates in the projector menu can help when writing on a whiteboard. There are four types of line templates to choose from.

CPAW3001 Cloning function Wireless Presentation Compatible
Connect the projector to a computer or your network using the
optional USB wireless adapter (part number USBWL5G). The adapter supports IEEE802.11.

CPAW3001 Cloning function 5 Year / 20,000* Hours Light Source Warranty
The new laser phosphor light source offers approximately 20,000 hours (normal mode) of operation time and is virtually maintenance free. There is no lamp to replace providing a dramatic reduction in total cost of ownership.
*5 Years or 20,000hrs. Whichever comes first

  Built-in Scheduler
Allows easy management of the unit.

  Crestron, Extron, AMX certified
Allows ease of use with their products.

Specifications

Panel Size 3 LCD 15mm (0.59" )
Panel Structure 3LCD
Resolution WXGA (1280 x 800)
Light Output (Brightness) ANSI Lumens LP-TW3001: 3300 (Normal)
Contrast Ratio 500,000:1
System (Hours) 20,000
Lens Built-in
Lens Zoom Digital zoom x 1.35
Lens Focus Powered focus
Projection Lens F Number 1.6
Throw Distance 0.413m - 0.903m (centre of glass to screen)
Throw Ratio (:1)
0.3
Diagonal Display Size
60 - 130"
Installation Ceiling, Tabletop, Rear
Speakers 16W mono
Digital Keystone Correction (Degrees) Horizontal: ± 5º / Vertical: ± 5º
Picture Modes Normal, Cinema, Dynamic, Whiteboard, DICOM SIM, User-1, User-2, User-3
Picture Adjustments ASPECT selection (Normal/4:3/16:9/16:10/14:9/Zoom/Native),
Perfect Fit (4 corners and 4 sides), Frame Lock (Data signal with
vertical frequency of 49 to 51 Hz, 59 to 61 Hz), HDCR, Image
blank by RS232C/Remote control, Image Optimizer, Magnify,
Mirror Reverse Image, Up-side Down Image
Operating Features Keystone V/H, PerfectFit, Standby Audio, Audio pass through, Cloning function, Easy schedule setting
Network Features
Wireless Capability(Option), Multi Projector, Moderator
Control Mode, Projector Quick Connection (iOS / Android
app), Projector Monitoring and Control from a Remote
Location, E-mail Alerts
Security Features Password/Myscreen Password, Pin Lock, Key Lock
Supported Languages 34 Languages (English, French, German, Spanish, Italian,
Norwegian, Dutch, Japanese, Portuguese, Simplified Chinese,
Traditional Chinese, Korean, Swedish, Russian, Finnish, Polish,
Turkish, Arabian, Persian, Czech, Danish, Hungarian, Romanian,
Slovenian, Croatian, Greek, Lithuanian, Estonian, Latvian, Thai,
Portuguese(Brazil), Indonesian, Vietnamese, Hebrew)
Digital Input HDMI x 2 (HDCP compliant, HDMI 2 shared with MHL)
Analogue Input 15-pin Mini-D-Sub x 2, RCA Jack x 1
Video Output 15 pin Mini D-Sub x 1 (shared with analog computer input)
Audio Input 3.5mm Stereo Mini Jack x 2, RCA Jack (L/R) x 1
Audio Output 3.5mm Stereo Mini Jack x 1
RS-232C Control 1 x 9-pin D-Sub
Wireless LAN USB-WL-5G (IEEE802.11 a/b/g/n/ac: 2.4GHz/5GHz) (optional)
Wired LAN RJ45 connector x 1
USB Type-A USB Type A x 2 (PC less Presentation or Wireless adapter)
USB Type B USB Type B x 1 (USB display or USB mouse control)
Power Supply AC 100V – 120V / AC 220V – 240V (50/60Hz)
Operating Power Consumption LP-TW4001: 350W / LP-TW3001: 280W
Standby Power Consumption Less than 0.5W
Weight LP-TW3001: 7.4Kg
Dimensions (W x H x D) 512 x 424 x 155mm
Noise (Normal) 34dB (Normal), 28dB (Eco)
Filter Life (Hours) 20,000
Certification CE Marking, EN61000-3-2, EN61000-3-3, EN55032
(class A), EN55024(EMC directive), EN60950-1
(Low voltage directive), WEEE/RoHS compliant
Computer IBM Compatible VGA, SVGA, XGA,WXGA, WXGA+/SXGA/
SXGA+/UXGA (compressed)
Video 525i (480i), 525p (480p), 625i (576i), 625p (576p)
1125i (1080i@50/60), 1125p (1080p@50/60)
Supplied Accessories Power Cable (1.8m) x1, Computer Cable (2m) x1, Remote
Control Unit x1, Concise User Manual x1, Security Label x1,
Adapter Cover x1, Hook Metal x1, Screw x1, HDMI Cable
Holder (x2), Cable Tie (large x1, medium x2, small x1), AA
Batteries x2, Interactive Pen x2, Pen Tip x4, AAA Batteries x4
LP-TW3001 Optional Accessories USB wireless adaptor USB-WL-5G, Wall mount unit: HAS-
WM06 (In some buying conditions wall mount is included),
Finger Touch Unit (FT-01B), Interactive Pen (I-PEN4)
Filter UX43251
Remote Control HL03037
Projector/ Light source Warranty 20,000 hours / 5 years (whichever comes first)



Rear Panel
LPTW3001 Rear



Optional Accessories

Kensington 2.4Ghz Wireless Presentation Remote - With Red Laser Pointer
Your Price:
$74.95

Special
Normally $99.95

Projector Remote

FEATURES

  • Wireless range up 50 meters
  • Red Laser Pointer
  • Low battery indicator
  • Backlit buttons
  • Two modes—switch from presenter to cursor control mode
  • On/off switch
  • USB receiver stores inside
  • Carry pouch included
  • Controls Keynote and PowerPoint

- Windows Compatible
- Mac Compatible
[More Information]


Universal Flush Projector Ceiling Mount FB-1 *Recommended*
White - $149
Black - $149


Projector Mount

SPECIFICATIONS
Available in BLACK (FB-1B) and WHITE (FB-1W)
• Swivel: 360°, Adjustable roll, pitch and yaw.
• Rigid Steel construction.
• Durable powder-coated finish (Black or White).
• Supports up to 10kgs.
• Mounting hardware included.
• User manual included.
• All bracket models come standard with 4 x mounting arms.

FEATURES
- Direct to ceiling mount (150mm)
- Suits most projectors with 3 or 4 holes


HDMI Logo

HDMI Cable

Premium HDMI 1.4 Digital AV Cable - For 3D Projectors

2 Metres
$29.95
5 Metres
$49.95
10 Metres
$79.95
15 Metres
$99.95
20 Metres
$149.95

High Speed HDMI cable is ideal for use with your Foxtel IQ2, PS3, Blu-Ray, HDTV and home theatre installations. It‘s an affordable, quality cable which features 24K gold plated contacts for optimal conductive ability and resistance to tarnishing and corrosion.

  • High Speed HDMI 1.4 CAT2 cable
  • Bandwidth: 340MHz / 10.2Gbps
  • ATC (Authorised Test Centre) certified for high speed
  • Supports resolutions up to WQXGA (2560 x 1600p) and Quad Full-HD (3840 x 2160p)
  • Supports all 3D formats
  • Deep Colour, x.v.Color™ and xvYCC compatible
  • Shielded cable construction for optimum RF and EMI protection
  • Low profile design, ideal for recessed connectors
  • 10 year warranty
