|Optoma EH502 Throw Distance Chart (Examples for common Sizes) T/R: 1.4-2.24:1
(Approx. To Lens)
|92" (16:9) 2030x1140mm
||From 2.9m to 4.5m
|100" (16:9) 2130x1200mm
||From 3.0m to 4.7m
|110" (16:9) 2435x1370mm
||From 3.5m to 5.4m
|120" (16:9) 2580x1450mm
||From 3.7m to 5.7m
Native Resolution: WUXGA 1920 x 1080 16:9
Brightness: 5000 ANSI Lumens
Maximum Contrast: 15,000:1
Fan Noise: 30db (eco)
Warranty: 3 Years (+1 Year $135)
Lamp Warranty: 12months/1000hrs
Lamp Life Up To: 7,000hrs
- Horizontal & Vertical Keystone
- 2x HDMI Connection
- MHL Compatible
- 1.5x Zoom
- Vertical Lens Shift
- Powerful 2x 16W Speaker
- 3D Capable(3D glasses required)
- Optional Wireless
Spectacular Image Quality with Ultimate Reliability
Optoma EH/X/W502 was designed to deliver unsurpassed performance and reliability to meet your installation needs. Its powerful 5,000 lumens output and impressive 15,000:1 contrast ratio deliver remarkably bright presentations with sharp text and color-rich graphics. To ensure it will perform to your needs, EH/X/W502 features a comprehensive I/O panel and advanced features. HDMI for digital connectivity, over-the-network presentation capability, wireless presentation capability via optional
USB dongle, vertical lens shift and discrete audio inputs including microphone input for maximum installation convenience.
Network Control Capability
EH/X/W502 can be monitored over LAN and provide the user email
message alert in case an error occurs or a lamp fails or needs to be
replaced using Crestron Roomview. The web browser interface and full
support for Telnet, Extron’s IP Link, AMX Dynamic device discovery and
PJ-Link protocols, allow almost all aspects of the EH/X/W502 to be controlled across a network, keeping you in control, wherever you are.
Vertical Lens Shift
Vertical lens shift gives you the ability to move the projected image up or
down, while keeping the projector stationary. This makes it easier to
position the projector in your room and enables a wider range of screen size options.
Turn EH/X/W502 into a smart display by connecting your smartphone or
tablet with a single cable using MHL, enabling you to view presentations and documents, stream videos and share photos on the big screen.
Individually warp each corner of the image to create a perfectly square
image. This funciton is ideal for image stacking, uneven walls or where
projector placement is awkward and needs to be installed at an angle.
USB power can be used to power a HDMI dongle, such as Google
Chromecast or the Optoma WHD200 wireless HDMI device.
EH/X/W502 supports HDMI 1.4a 3D playback, including 3D 1080P
Blu-ray, 3D gaming consoles like PS4, XBOX360 native 3D games, and
3D broadcasting signal, just connect Full HD 3D player directly to
EH/X/W502 via HDMI, you can instantly become part of a fantastically
immersive experience . The 3D effect isgenerated by splitting this signal
into two standard video streams, one for each eye. Using DLP® Link™ technology, the 3D glasses synchronise with the image on screen to filter
each stream to the correct eye. Your brain then combines the two
streams to make them jump into life.
A Full HD projector with 1920x1080 pixels has more than twice the resolution of an HD-Ready display. Fully compatible with HDTV broadcasts and high definition media, the EH501 is able to display un-scaled 1080p signals in their original form for use where exceptional clarity and detail are essential.
Easy installation - 1.5x zoom and lens shift
The EH502 can project a 100” diagonal image from any distance between 3.03m and 4.54m. The Lens Shift system can be used to adjust the vertical position of the projected image within the range detailed in the diagrams below.
When replacing existing projectors, the 1.5x zoom and Lens Shift systems greatly increase your installation flexibility.
Clear, focused Images
DarkChip3™ from Texas Instruments, combined with Eco+ dynamic lamp technology produce a stunning 15,000:1 contrast ratio for pin sharp graphics and crystal clear text. Crisper whites, ultra-rich blacks makes images come alive and text easier to read - ideal for business and education presentations.
The EH502 incorporates BrilliantColor™ technology to produce stunningly bright images with perfectly balanced, life-like colours.
|Easy lamp replacement
In applications requiring smooth continuous operation, minimising service time is essential. The EH502 lamp can quickly be replaced without the need to remove the projector from where it is installed.
