Optoma EH512 DLP Full HD High Brightness Projector
Specifications
- 1080p 1920 x 1080 16:9
- 5000 ANSI Lumens
- 15,000:1 Contrast
- 4.6kg Weight
- 30db (eco) Fan Noise
- 2 Year Warranty
- 12months/1000hrs Lamp Warranty
- Est. Lamp Life up to 7,000hrs
Key Features
- Horizontal & Vertical Keystone
- 2x HDMI Connection
- 1.5x Zoom
- USB to Smarphone (Andriod/iOS)
- USB Reader Jpeg, PDF,
- USB Reader Word, Excel, Powerpoint
- Vertical Lens Shift
- Powerful 2x 10W Speaker
- 3D Capable(3D glasses required)
Optoma EH512 Throw Distance Chart
Throw Ratio: 1.4-2.24:1| Image Size | Installation Distance | |
|---|---|---|
| 92" (16:9) 2030x1140mm | From 2.9m to 4.5m | |
| 100" (16:9) 2214x1245mm | From 3.1m to 4.9m | |
| 110" (16:9) 2435x1370mm | From 3.5m to 5.4m | |
| 120" (16:9) 2657x1494mm | From 3.7m to 5.7m | |
| 135" (16:9) 2990x1681mm | From 4.2m to 6.6m | |
| 150" (16:9) 3320x1867mm | From 4.7m to 7.4m | |
Professional Installation 1080p Projector EH512
The Optoma EH512 is perfect for large venue installations with a powerful brightness of 5000 lumens being able to project in a well lit area. The 1080P resolution produces crisp clear images even with a large image size. The EH512 is also very flexible to install with a 1.6x optical zoom, vertical lens shift and both vertical and horizontal keystone correction making it easy to install even in a tricky position. Also known as the EH512WL can beome wireless with an optional wireless adapter.
- Bright 1080p projection featuring 5,000 lumens and 15,000:1 contrast ratio
- PC-free USB image viewer and office document reader
- Wireless presentations and images (USB Wi-Fi adapter Optional)
- USB display screen mirroring with iOS and Android devices
- LAN display via Ethernet with Windows and Mac OS X
- Vertical lens shift, keystone correction and full RS-232C control
Bright projection with installation flexibility and control
Experience brilliant 1080p projection with the 5,000 lumen Optoma EH512. Its 15,000:1 contrast ratio, 1.6x zoom, vertical lens shift, keystone correction and full RS-232C control provide installation flexibility ideal for large classrooms, lecture halls, museums and houses of worship.
A PC-free image viewer and document reader display office documents, PDFs and images from USB storage devices. HDCast Pro connectivity provides wireless screen mirroring with Android, Mac OS and Windows devices.
LAN display supports up to 4 simultaneous computers while USB display mirrors Android and iOS devices. Robust input options include HDMI, VGA and analog for easy connectivity to current and legacy video sources.
DLP Technology
DLP® (Digital Light Processing) is a proprietary technology from Texas Instruments that offers digital projection with higher contrast, faster response time, good pixel structure and virtually no color degradation.
Image quality
A Full HD projector with 1920x1080 pixels has more than twice the resolution of an HD-Ready display. Fully compatible with HDTV broadcasts and high definition media, the EH512 is able to display un-scaled 1080p signals in their original form for use where exceptional clarity and detail are essential.
PC-free USB Image and Document Viewer
Integrated PC-free image and document viewer provide direct viewing of office documents, PDFs, images and presentations from any USB storage device.
Vertical Lens Shift
Vertical lens shift simplifies installations by shifting the image up and down without image distorsion to provide a wider range of projector placement possibilities, making it easier to position the projector in a room.
Clear, focused Images
DarkChip3™ from Texas Instruments, combined with Eco+ dynamic lamp technology produce a stunning 15,000:1 contrast ratio for pin sharp graphics and crystal clear text. Crisper whites, ultra-rich blacks makes images come alive and text easier to read - ideal for business and education presentations.
+12v Trigger
Easily trigger a motorized screen to lower or raise when the projector is powered on or off.
AMX Compatibility
Easily communicate with AMX control systems for simple integration.
Creston Roomview® – NETWORK CONTROL Roomview®
Software provides a custom configurable interface to monitor, manage and control every device in every room remotely from any computer.
- Manage up to 250 projectors at the same time (via master PC).
- Control and alter the projector settings using a simple web browser page, including OSD menu control.
- Set up email alterts for warning messages.
- Ideal for large installations in both educational and business environments.
RS-232 Control
Take control of the projector using HEX or ASCII commands via RS-232 cable.
Easy lamp replacement
In applications requiring smooth continuous operation, minimising service time is essential. The EH512 lamp can quickly be replaced without the need to remove the projector from where it is installed.
| Aspect Ratio | 16:9 (native), 16:10, 4:3, LBX and auto compatible |
|---|---|
| Audio | 2 x 10W speakers (stereo) |
| Brightness | 5,000 ANSI Lumens |
| Color Wheel | 6 segment RYGCWB |
| Contrast Ratio | 15,000:1 |
| Display Technology | Single Texas Instruments 0.65” 1080p DMD |
| Displayable Colors | 1.07 Billion |
| Geometry | Four corner adjustment |
| Image Size | 26.2” – 301.1” |
| Inputs | 2 x HDMI, 1 x VGA, 1 x composite, 1 x S-Video, 1 x audio (3.5mm) |
| Keystone Correction | ±20° Vertical ±20° Horizontal |
| Light Source Life | 7,000/6,000/5,000/3,000 (Eco+/Dynamic/ECO/Bright) |
| Lens Shift | Vertical lens shift 16% |
| Light Source | Lamp (330W) |
| Maximum Resolution | WUXGA (1920 x 1200) |
| Native Resolution | 1080p (1920 x 1080) |
| Noise Level | 30dB (ECO) |
| Offset | 100% |
| Operating Temperature | 41–104°F (5–40°C), 85% max humidity |
| Outputs | 1 x VGA, 1 x USB (Wi-Fi adapter), 1 x USB (USB display, service), audio out (3.5mm) |
| Power Consumption | 405W typical (Bright), 445W max (Bright), 315W typical (Eco), 347W max (Eco) |
| Power Supply | AC input 100–240V, 50–60Hz, auto-switching |
| Projection Distance | 4.2’ – 49.1’ (without zoom) |
| Projection Lens | F=2.5-3.25; F=20.91-32.62mm |
| Projection Method | Front, rear, ceiling mount, table top |
| Remote Control | Full size remote with laser |
| Throw Ratio | 1.41 – 2.24 |
| Uniformity | 70% |
| Zoom Type | 1.6x optical, 0.8 – 2.0x digital |
| 3D Compatibilty | Supports all HDMI 1.4a mandatory 3D formats (Frame pack, side-by-side, top-bottom) and up converts frame rate from 60Hz to 120Hz or 24Hz to 144Hz (i.e. 60 or 72 frames per eye). |
| Computer Compatibilty | VGA, SVGA, HDTV(720P), WXGA, WXGA+, SXGA, SXGA+, UXGA, HDTV(1080p), WUXGA |
| Horizontal Scan Rate | 15.375 – 91.146 KHz |
| Vertical Scan Rate | 24 – 85Hz (120Hz for 3D) |
| Dimensions | 36 x 29.5 x 13.5cm |
| Security | Kensington® lock port |
| Weight | 4.6 kg |
| Accessories | AC power cable, remote control, batteries, USB Wi-Fi adapter |
| Specifications | |
| Video Input | PAL, SECAM, 576i/p, NTSC, 480i/p, HDTV 720p/1080i/1080p |
Remote Control
Power Cord
Rear Panel
Optional Accessories
