Panasonic PT-RW330EA Large Venue HD Widescreen Projector




Solid State

Your Price: $2299

Flat Rate Freight!
$22 Insured Australia Wide.
Pick up Available


SOLID SHINE series uses the newly developed LED/Laser-combined light source

SOLID SHINE series projectors provide solid reliability and long-lasting brightness unprecedented by conventional lamp-based projectors.

Approximately 20,000 hours*1 of maintenance-free operation
No need to replace the light source or air filter, providing a dramatic reduction in the Total Cost of Ownership (TCO).

Long-lasting picture quality
Excellent picture quality and brightness are maintained for a long time. Superb color reproduction Beautiful, vivid colors exceeding the levels of conventional projectors.

Quick start, quick off
The image appears almost instantly upon powering up, and there is no need for cooling after turning the power off. The power can be turned on immediately after being turned off, and it can be turned on/off as many times as you want.


Long-Lasting Reliability and High Picture Quality

The LED/Laser-Combined Light Source Enables Approx. 20,000*1 Hours of Continuous Operation
This new light source requires no maintenance for approximately 20,000 hours. *1 In many cases, this means no maintenance until your next refresh cycle. Naturally, there are no lamp burnout problems during use, so reliability is further increased. There is also no filter to clean due to carefully engineered sealed optics. As a consequence, running cost is dramatically lowered because of the savings on lamp costs, maintenance labor and hassle of stocking lamps.

Bright, Beautiful Picture Quality for a Long Period of Time
The PT-RZ370/RW330 features 3,500 lumens of brightness. Rate of brightness deterioration in the LED/Laser-combined light source is extremely slow compared to lamp based projectors. The SOLID SHINE drive uses a built-in sensor to constantly detect the light intensity of the light source and correct corresponding changes in white balance. This all helps to maintain excellent picture quality for a long period of time. Contrast is outstanding too, at 10,000:1, and images are reproduced with a wide dynamic range. The PT-RZ370 features a Full-HD (1920x1080) DLP™ chip, allowing highly detailed Full-HD images without resizing.

Superior Color Reproduction
The LED/Laser-combined light source has a higher level of color purity than an ordinary lamp, allowing it to achieve color production with wider color space. Colors are more vibrant than those of conventional projectors.

30x Drive*3 Switching Prevents Color Breaking
In 1-chip DLP™ system projectors with conventional lamp, a color wheel is used for time-division multiplexing in a method where the human eye combines the result to achieve a full-color palette. In the PT-RZ370/RW330, this is done by on/off switching of the LED/Laser-combined light source. A unique Panasonic power supply circuit provides time-division multiplexing with ultrafast 30x drive.*3 The resulting, high-definition images exhibit virtually no color breaking.*4

Heat Pipe Cooling System Maintains Stable Operation up to 45 °C (113 °F)*5
Laser cooling is performed by releasing the heat to cooling fins, then cooling with a heat pipe cooling system. This suppresses temperature rises inside the projector and allows stable operation up to an ambient temperature of 45 °C (113 °F).*5 The use of this heat pipe-cooled system also achieves quiet operation of 29 dB,*6 enabling viewers to concentrate on thepresentation or on quiet movie scenes.
Heat Pipe

Dust-Resistant Structure with an Airtight Optical Block
The area between the LED/Laser to the DLP™ chip and prism is hermetically sealed to form an airtight structure for the optical block, the heart of the projector. This resists the effects of dust and other particles in the air, and enables use of the projector in a wide range of environments.

The Daylight View Basic Ensures Clear Images Even in Brightly Lit Rooms
PANASONIC Daylight View Basic TECHNOLOGY achieves sharp, easy-to-see images by clearly reproducing the details in dark image areas, which were previously difficult to see in brightly lit rooms. A built-in sensor measures the ambient light, and the Daylight View Basic function adjusts the halftone color and brightness level according to the surrounding illumination.


DICOM Simulation Mode *7
This imaging mode is similar to DICOM part 14, which is a medical imaging standard. It reproduces X-ray images with remarkable clarity.

Rec. 709 Mode for HDTV Projection
Optimal color reproduction can be achieved by selecting this mode, compliant with ITU-R Recommendation BT.709, when images from an HDTV source are projected.

*1 A guideline for light source replacement. The maintenance-free period may be shortened due to environmental conditions.
*2 Use a CAT5e (STP) cable or higher.
*3 Picture mode: Dynamic. 10x drive in other picture modes. The rate for each vertical sync/blanking interval, with R/G/B light source switching set to 1x.
*4 A condition in which incorrect color expression causes color flickering.
*5 The operating temperature range is 0 °C to 40 °C (32 °F to 104 °F) when used in locations from 1,400 m to 2,700 m (4,593 ft to 8,858 ft) above sea level.
*6 LIGHT POWER mode: ECO. 35 dB with LIGHT POWER mode set toNORMAL.
*7 This product is not a medical instrument. Do not use it for actual medical diagnosis.

Versatile First-Time and Replacement Installations

2x Zoom Lens: For a 120-inch-diagonal wide screen, the projection distance extends from approximately 3.9 m (12.8 ft) to approximately 7.8 m (25.7 ft).

Projector Zoom
Horizontal/Vertical Lens Shift: The wide shift range accommodates various room sizes and shapes. When lights or ventilation holes are located in the ceiling mounting site, you can simply relocate the projector to avoid them. Lens Shift
Flexible 360-Degree Installation: The projectors can be rotated vertically. This means you can install one at any up-and-down angle you want, to accommodate different installation conditions. 360 degree installation
Lens-Centered Design: A lens-centered, symmetrical design provides ease of installation, eliminating the need for any special considerations when planning the installation site.
Centered Lens

DIGITAL LINK Transmits Digital Signals up to 100 m (328 ft) with a Single Cable *2
Optional ET-YFB100G Digital Interface Box for Easy Setup: By combining the optional ET-YFB100G Digital Interface Box, with its HDMI and other input terminals, uncompressed HD digital video, audio and control signals can be transmitted up to 100 m (328 ft) over a single LAN cable. *2 It allows projector connection with only one cable, making it ideal for ceiling-mounted and other permanent installations. Also, because control signals can be simultaneously transmitted, the ET-YFB100G input signal can easily be switched with the wireless remote control that is included with the projector. The projector can be controlled by either serial or LAN communication.

Digital Link

Also Supports Other Manufacturers’ Peripheral Equipment: DIGITAL LINK is an original function added to technology based on the transmission standards used in Crestron’s DigitalMedia 8G+, Extron’s XTP Systems, etc. Signals from the ET-YFB100G canalso be relayed to a non-DIGITAL LINK-ready projector by using another manufacturer’s equipment based on the same technology.*8

Digital Link

Abundant Connection Terminals, Including HDMI
Interfaces include HDMI and DVI-I inputs. The serial terminal (RS-232C) has an Emulate func-tion that lets you continue using existing control systems when replacing previous Panasonic models. It is also possible to output audio dur-ing STANDBY MODE.
*9 This is convenient when connecting an external audio system through the projector.
*10 A closed caption decoder is built in.

Easy Remote Monitoring and Control over a LAN
Web browser on a computer connected through a wired LAN system lets you remotely operate projectors and check their status. An e-mail messaging function can also notify you the overall projector status. In addition, Multi Projector Monitoring and Control Software Ver. 2.8 is available for monitoring and controlling multiple Panasonic projectors from a single PC. The wired LAN terminal is compatible with PJLink ™ (class 1), an open protocol that is used by many manufacturers, to enable integrated control of systems that contain different brands of projectors.

Operation Friendly

Image Appears Immediately—No Need for Cooling after Use
Images do not appear quickly with lamp-based projectors because the projector requires time to warm up. With the PT-RZ370/RW330, the image appears almost instantly. There’s also no cooling time required when turning the power off, so you can quickly turn the projector on and off as many times as needed.

24/7 Operation
Ordinary lamps are not well suited to continuous operation. Because the PT-RZ370/RW330 does not use a lamp, has efficient cooling system and uses DLP™ chip that has a long life, they are capable of 24/7 operation.

Scheduling Function
Scheduled operation is possible using the built-in timer function, without having to use a PC and software.
Effective Theft Prevention with the Startup Logo
You can change the default Panasonic start up logo to any logo you want. A new logo can be easily uploaded by connecting a computer to the PT-RZ370/RW330 through the LAN or serial connection by using the Logo Transfer Software. *11 An abundance of other security measures are also included, such as a security bar, Key lock, and Security Password. This is very effective for preventing theft.

15 m (49 ft) Long-Range Wireless Remote Control
A unique ID number can be assigned to each projector using the supplied wireless remote control unit. This allows operation of a desired projector when multiple units are set up at the same location. Three frequentlyused functions can be assigned to the Function buttons for instant recall.

Eco Management Functions
A number of functions are provided to reduce power consumption. You can easily set the Eco Management functions according to operatingconditions by using the “ECO” button on the remote control.
- Selectable light source modes:
NORMAL: Prioritizes brightness.
ECOSAVE1: Reduces power consumption by approximately20% on average while leaving brightnessalmost unchanged.
ECOSAVE 2: Minimizes
brightness reduction while reducing power
consumption by approximately 30% on average.
LOW: Prioritizes low power consumption.
- Adjusts the brightness according to ambient light conditions, and reduces the light source power.
- Reduces the light source power when there is no signal input or the projector is in AV Mute mode.

Projector Screen Bundle

Model PT-RZ370 PT-RW330
Power supply 100-240 V AC, 5.2-2.0 A, 50/60 Hz
Power consumption 460 W (470 VA) (250 W*1 with LIGHT POWER set to NORMAL,
200 W*1 with LIGHT POWER set to Ecosave1, 178 W*1 with LIGHT POWER set to Ecosave2)
(0.5 W with STANDBY MODE set to ECO*2, 8 W with STANDBY MODE set to NORMAL)
DLP™ chip Panel size 16.5 mm (0.65 inches)
diagonal (16:9 aspect ratio)
16.5 mm (0.65 inches)
diagonal (16:10 aspect ratio)
Display method DLP™ chip x 1, DLP™ projection system
Pixels 2,073,600 (1,920 x 1,080) pixels 1,024,000 (1,280 x 800) pixels
Lens Manual zoom (2.0x), manual focus lenses, F 2.0–3.4, f 21.5–43.0 mm
Throw ratio 1.46-2.94:1 1.53-3.09:1
Light source LED/Laser-combined (R, B: LED; G: Laser diode)
Screen size (diagonal) 1.02-7.62 m (40-300 inches), 16:9 aspect ratio 1.02-7.62 m (40-300 inches), 16:10 aspect ratio
Brightness*3 3,500 lm
Center-to-corner uniformity*3 90 %
Contrast*3 10,000:1 (full on/full off)
Resolution 1,920 x 1,080 pixels
(Input signals that exceed
this resolution will be converted
to 1,920 x 1,080 pixels.)
1,280 x 800 pixels
(Input signals that exceed
this resolution will be converted
to 1,280 x 800 pixels.)
Scanning frequency HDMI/DVI-I(digital) fH: 27-100 kHz, fV: 24-120 Hz, dot clock: 25-162 MHz
DVI-I(analog)/RGB fH: 15-100 kHz, fV: 24-120 Hz, dot clock: 162 MHz or lower
fH: 15.75 kHz, fV: 60 Hz [480i (525i)]
fH: 31.50 kHz, fV: 60 Hz [480p (525p)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1035 (1125)/60i]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]
fH: 33.75 kHz, fV: 30 Hz [1080 (1125)/30p]
fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p]
fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
fH: 28.13 kHz, fV: 25 Hz [1080 (1125)/25p]
fH: 27.00 kHz, fV: 48 Hz [1080 (1125)/24sF]
fH: 67.50 kHz, fV: 60 Hz [1080 (1125)/60p]
Video fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Optical axis shift Vertical +73%, -48% from center of screen (manual) +69%, -46% from center of screen (manual)
Horizontal +27%, -35% from center of screen (manual) +28%, -37% from center of screen (manual)
Keystone correction range Vertical: ±40 °
Installation Ceiling/floor, front/rear
Terminals HDMI IN HDMI 19-pin x 1 (Deep Color, compatible with HDCP)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/24sF,
1080/25p, 1080/30p, 1080/60p, 1080/50p,
VGA (640 x 480)-WUXGA (1,920 x 1,200)*4,
compatible with non-interlaced signals only, dot clock: 25-162 MHz,
audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
DVI-I IN DVI-I 29-pin x 1
Digital: (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/24sF,
1080/25p, 1080/30p, 1080/60p, 1080/50p,
VGA (640 x 480)-WUXGA (1,920 x 1,200)*4,
compatible with non-interlaced signals only, dot clock: 25 -162 MHz;
D-Sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR x 1)
VIDEO IN Pin jack x 1 (Composite VIDEO)
AUDIO IN M3 x 1 (L-R x 1)
AUDIO OUT M3 x 1 (L-R x 1) for output (variable)
SERIAL IN D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
(for network and DIGITAL LINK (video/audio/network/serial control) connection,
100Base-TX, compatible with PJLink™, HDCP compatible, Deep Color compatible)
480p, 576p, 720/60p, 720/50p,
1080/60i, 1080/50i, 1080/24p, 1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p,
VGA (640 x 480)-WUXGA (1,920 x 1,200)*4,
compatible with non-interlaced signals only, dot clock: 25-162 MHz
Cabinet materials Molded plastic
Dimensions (W x H x D) 455 x 137*5 x 415 mm (17-29/32 x 5-13/32*5 x 16-11/32 inches) (lens included)
Weight*6 Approximately 11.0 kg (24.3 lbs)
Operation noise*3 35 dB ( LIGHT POWER mode: NORMAL), 29 dB ( LIGHT POWER mode: LOW)
Operating environment Operating temperature: 0-45 °C*7 (32-113 °F*7),
operating humidity: 20-80 % (no condensation)
Supplied accessories Power cord (with secure lock) x 1*8, wireless remote control unit,
batteries for remote control (R6/LR6/AA type x 2),
software CD-ROM (Logo Transfer Software, Multi Projector Monitoring & Control Software)
Rear Panel
